Insite® Surgery Table
PART #6844




















Insite® Surgery Table
PART #6844
A flexible and radiolucent cantilevered surgery table useful for many spine and imaging procedures.
Contemporary imaging platform
The Insite Multi-Procedural Surgery Table offers a radiolucent, cantilevered frame designed to give surgeons better imaging access during many types of procedures, including those requiring total access to the spine. Easy-to-set up with a small OR footprint, Insite easily converts from an open frame spine platform to an imaging platform.
Product features
- Unobstructed imaging up to 55” (140cm) no metal zone
- Interfaces with the BodyTom®, a portable, full body, multi-slice CT scanner
- Unrestricted O-arm® and C-arm access
- Universal Side Rail Adaptor and Retractor Adaptor for mounting ancillary equipment
- Rail Mounted I.V. Pole keeps the floor clear for easy access of imaging devices
- Backlit hand pendant controls all table functions, including floor locks, height, lateral roll, Trendelenburg/ reverse Trendelenburg and return to level
- Tempur-Pedic® pad technology incorporated into all patient surfaces
- ProneView® Protective Helmet System offers head and eye protection for the prone patient
- Cervical mounting device for cranial stabilization options
- Self-compensating power floor locks
- Low-profile base with stainless steel shroud
- AC or battery-operated
- Emergency stop
- Emergency floor lock override system
- Standard OR accessory rails on pedestal end
Positioning capabilities
PRONE |
SUPINE |
LATERAL |
Patient head orientation can be at the cantilever or the pedestal end
BodyTom® is a registered trademark of NeuroLogica Corp.; O-arm® is a registered trademark of Medtronic, Inc.
Common procedures
- Laminectomies
- Decompressions
- Spinal fusions
- Osteotomies
- Posterior cervical
- Surgical correction of deformities
- Vascular surgery
- Joint imaging
- Pain management
Warranty
We guarantee all our products for a period of one year from the date of shipment from Mizuho OSI for defects in material and workmanship with the exception of products which are misused, altered or damaged.
Patents
- US 8,397,323
- US 9,713,562
- US 10,888,481
Product specifications
Total table length | 90” (229cm) |
Table top length | 85” (216cm) |
Pedestal top width | 21” (53cm) |
Pedestal top length | 30” (76cm) |
Imaging area length | 55” (140cm) |
Imaging area width | 21” (53cm) |
Height range | 32–42” (81–107cm) |
Trendelenburg / Reverse Trendelenburg | 15° |
Lateral roll (tilt) | ± 20° |
Patient weight capacity | 450lbs (205kg) |
Standard components
- Hand Pendant
- Patient Safety Straps (2)
- Insite ProneView Patient Care Kit (3/case)
- Power Cord
- Table Storage Cover
Prone positioning
- ProneView Protective Helmet System
- Face Plate
- Tempur-Pedic Medical Chest Pad
- Contoured Tempur-Pedic Medical Hip Pads (1 pair)
- Arm Board Mounting Bracket
- 5-Way Articulating Arm Boards (2)
- Pedestal End Arm Board Mounting Brackets (2)
- Leg board with Tempur-Pedic Medical Pad, 1” (2.5cm)
- Retractor Adaptor, prone frame
- Buttocks Strap
- Cervical Mount, Coupler II Main Assembly
Supine positioning
- Supine Top, 1” (2.5cm) Tempur-Pedic Medical Pad
- Universal Side Rail Adaptor, Supine Top (2)
Accessories (20)





Part #5873-300
DORO® Radiolucent Adaptor for the Coupler II
DORO® is a registered trademark of pro med instruments GmbH.

Part #6910-1001
DORO® QR3 Aluminum Skull Clamp
DORO® is a registered trademark of pro med instruments GmbH.

Part #6910-4004
DORO® Radiolucent Skull Clamp
DORO® is a registered trademark of pro med instruments GmbH.



Part #6900-23
Rail Mounted IV Pole










Part #6844-30
Insite Table Cover
